Needle Fel Filter Bag（POS/PES）
Needle felt filter bag is made of 100% heat-treated original material, clean and safe with uniform pore size to ensure a satisfactory filtering effect. The standardized sealing ring opening, and all-welded structure ensure zero side leakage.
All materials used in manufacturing comply with the regulations of fda, title 1. section 177 and ec directive 2002/72/ec, as applicable for food and beverage contact.
Overview
-
Retention ratings
1-300μm
-
Max.differential pressure
2.5 bar
-
Recommended change-out pressure
0.8-1.5 bar
Core features
- Even fiber pore size for efficient filtration
- Hygienic and safenon-toxic and harmless
- It's hot-melt andall-welded structure ensure zero side leakage
- Sealed by various sealing rings for flexible configuration
- Material complies with the internationa regulations for food and beverage contact
Specification
Drawings
| Siza | Diameter（mm） | Length（mm） | Max flow rate（m³/h） | Filter area（m³） |
|---|---|---|---|---|
| 01 | 180 | 430 | 20 | 0.24 |
| 02 | 180 | 810 | 40 | 0.48 |
| 03 | 100 | 230 | 6 | 0.08 |
| 04 | 100 | 380 | 12 | 0.16 |
| 05 | 152 | 50 | 15 | 0.2 |
Performance Data
Product Specifications
| Product Code |
Material
|
Retention Ratings （μm） |
Sealing rings |
Max.operating temperature （℃） |
Max.differential pressure |
Recommendedchange-out pressure |
|---|---|---|---|---|---|---|
| POS-1 | Polypropylene | 1 | Welded polypropylene | 90 | 2.5 bar | 1.5 bar |
| POS-2 | Polyster | 5 | Polyester seal ring | 150 | 2.5 bar | 1.5 bar |
| POS-3 | Polypropylene | 10 | Stainless steel ring | 90 | 2.5 bar | 1.5 bar |
